Home > Products > Pressure Gauge Series > Precision Pressure Gauge
The precision pressure gauge consists of a pressure measuring system, a transmission mechanism, an indicator device, and a housing. The pressure measuring elastic element is treated with special technology to ensure stable and reliable performance of the precision pressure gauge. After being matched and debugged with a high-precision transmission mechanism,itcanensure accurate indication accuracy.Precision pressuregaugesare mainly used to calibrate ordinary industrialpressure gagcmda steels at the process site.
Company Name:Hengshui Longjie Instrument Co., Ltd.Inquiry Hotline:+86 17631885938Product List
productDetailed Description
Surface diameter: 4" (100mm), 5" (150mm)
Connection method: Thread
Casing: Carbon steel or stainless steel
Range: -0.1, 0.1, 0.16, 0.25, 0.4, 0.6, 1, 1.6, 2.5, 4, 6, 10, 16, 25, 40, 60
Table Window: Mpa
Movement: Copper tube and copper joint
Contact medium part: Glycerol or silicone oil or not filled with oil
Connecting thread: M20x1.5, 1/2 (other 'specifications can be customized)
Accuracy: 0.25%, 0.4%
